Rapiscan 520B
- The Rapiscan Model 520B is an x-ray security inspection system designed for customers requiring high performance functionality to meet demanding security concerns. Its compact design is well suited for security checkpoint areas such as airports, courthouses, embassies and prisons. The system offers a tunnel opening of 640mm (25.2 inches) wide by 430mm (16.9 inches) high to accommodate large package sizes.
- Intel Pentium computer technology is the driving force in all of our developments. Model 520B offers Crystal Clear as a standard feature and may be optionally equipped with Operator Training Program, Manual Image Archive and Enhanced Performance X-ray (EPX). EPX enables rapid and consistent detection capabilities, identifying material having specific characteristics of explosives and narcotics. Gold, currency and agricultural products can also be identified using EPX.
Physical Specifications
| Dimensions: | Length: 2590mm (102in) Height: 1345mm (52.95in)* Width: 840mm (33.10inc) |
| Tunnel Size: | 640mm(W) x 430mm(H) (25.2 x 16.93in) |
| Conveyor Speed: | 0.22M/Sec (44ft/min) |
| Conveyor Load: | 50Kg (110lbs) |
| Approx. Weight: | Net: 560Kg (1232lbs) Gross: 760Kg (1672lbs) |
Rapiscan 520b Manual Typewriters
Unit is mounted on heavy duty castors for ease of movement
*Nominal height + 1 inch adjustment
General Word import style from another document.
| Resolution: | 38 AWG guaranteed, 40 AWG typical |
| Penetration: | 27mm steel guaranteed, 29mm typical |
| Material Separation: | Low Z, Medium Z, High Z to 0.5 Z accuracy |
| Monitor: | 17 inch XVGA colour, high refresh, non flicker |
| Power: | 110VAC (+/-) 10% / 50 or 60Hz / 10Amps Max or 220VAC (+/-) 10% / 50 or 60Hz / 5Amps Max |
X-Ray Generator
| Cooling: | Sealed oil bath with forced air |
| Anode Voltage: | 160KV rated, operating @ 140KV |
| Tube Current: | 0.7mA typical |
| Orientation: | Vertically Upward |
Computer Specifications
| Processor Speed: | 833 MHz Pentium Processor minimum |
| Memory: | 64MB RAM minimum |
| Video Memory: | 16MB minimum |
| Hard Disk Drive: | 20GB minimum |
| CD-ROM Drive: | 40X Max Variable |
| Floppy Dish: | 1.44MB |
Access to keyboard port and parallel port is provided by means of a lockable access panel on the outside of the machine.
Environmental Requirements
| Storage Temperature: | -20C to 50C |
| Operating Temperature: | 0°C to 40°C |
| Relative Humidity: | 5 to 95% non-condensing |
Health & Safety Midi ox equivalent for mac.
All Rapiscan systems comply with applicable international health and safety regulations including USA FDA X-ray systems (Federal Standard 2.1-CFR 1020.40) and Health and Safety at Work Act 1974-section 6, Amended by the Consumer Protection Act 1987. Maximum leakage radiation less than 0.1mR/hr (1p Sv/hr) in contact with outer panels. Film Safety: For ISO 1600/33 DIN, guaranteed up to 10 times exposure to radiation.
HAWTHORNE, Calif. - July 20, 2005 - Rapiscan Systems, a division of OSI Systems, Inc. today announced that it will be deploying multiple security inspection solutions at this year's International Association of Athletics Federations (“IAAF”) World Championships taking place in Helsinki, Finland from August 6th through the 14th. The equipment will be installed in both the Olympic Stadium and its immediate surroundings, as well as in the Athletes' Village.
Rapiscan 520b Manual Driver
Specific systems include:
Rapiscan 520b Manual Download
- Rapiscan 520B X-Ray: Dual energy imaging that provides automatic color coding of materials with different atomic numbers so that screeners can easilyentify objects within a parcel or package.
- Metor 200 WP: A fully weatherproof, rugged multi-zone walk-through metal detector for harsh climates ranging from winter conditions to tropical environments.
- Metor 28: Hand-held metal detector that allows for an individual to be thoroughly and effectively scanned while eliminating the need for the inspector to make physical contact.
President of Rapiscan Systems, Mr. Ajay Mehra, stated, “With over 350,000 spectators expected at the event and an estimated four billion viewers around the world, it is absolutely imperative that safety for the games is above reproach. We understand the inherent security challenges and look forward to drawing upon our vast experience to meet the needs of the IAAF and the Finnish Police Force.”
About Rapiscan Systems Rapiscan Systems, a division of OSI Systems, Inc. is a leading supplier of high quality security inspection solutions utilizing X-ray and gamma-ray imaging, and advanced threatentification techniques such as neutron and diffraction analysis. The company's products are sold into four market segments; Baggage and Parcel Inspection, Cargo and Vehicle Inspection, Hold Baggage Screening and People Screening. The company has an installed base globally of more than 50,000 security and inspection systems. The Rapiscan Systems product line is manufactured at four locations and supported by a global support service network. For more information on Rapiscan Systems, please visit www.rapiscansystems.com .
Rapiscan 520b Manual User
About OSI Systems, Inc. OSI Systems Inc. is a Hawthorne, California based diversified global developer, manufacturer and seller of security and inspection systems, medical monitoring products, and optoelectronic-based components, as well as a provider of engineering and manufacturing services. The company has more than 30 years of experience in electronics engineering and manufacturing and maintains offices and production facilities located in more than a dozen countries. OSI Systems implements a strategy of expansion by leveraging its electronics and contract manufacturing capabilities into selective end product markets through organic growth and acquisitions. For more information on OSI Systems Inc. or any of its subsidiary companies, visit www.osi-systems.com.
Rapiscan 520b Manual User
This press release contains forward-looking statements within the meaning of Section 27A of the Securities Act of 1933, as amended, and Section 21E of the Securities Exchange Act of 1934, as amended. Such statements include information regarding our expectations, goals or intentions about the future, including, but not limited to, statements regarding the performance or market acceptance of our security products. The actual results may differ materially from those described in or implied by any forward-looking statement.Other important factors are set forth in our Securities and Exchange Commission filings. All forward-looking statements speak only as of the date made, and we undertake no obligation to update these forward-looking statements.
For Further Information
Rapiscan Systems Nithtisillankuja 5, P.O. Box 174 FI-02631 Espoo Finland +358 9 32941500 Contact: Petri Ikonen
